ACOPOSmulti auxiliary supply module, 32 A, AS, cold plate or pass-through mounting, 24VOut 1x 32 A, 1x 5 A

ACPMULTI NF 16A 480V

ACPMULTI NF 30A 520V

Line filter, passive, 55 A, 3x 520 VAC, 50/60 Hz, IP20

ACOPOSmulti mounting plate with backplane, 4 slots, AS, wall mounting, 75 mm² and 22 mm², complete

ACOPOSmulti mounting plate with backplane, 16 slots, AS, cold plate mounting, 75 mm² and 22 mm², complete

ACOPOSmulti mounting plate with backplane, 17 slots, AS, cold plate mounting, 75 mm² and 22 mm², complete

Passive power supply modules act as the central power supply for ACOPOSmulti drives and feed the DC bus. They are not subjected to a control loop and therefore cannot provide regeneration.The 8B0P0110HC00.000-1 passive power supply module has an integrated line filter and internal braking resistor. It is also possible to connect an optional external braking resistor. In addition, an interface for connecting 24 VDC is also available. This allows the internal 24 VDC supply to provide an ACOPOSmulti drive system with up to 90 watts of nominal power. This eliminates the need for an 8B0C auxiliary supply module in many applications. The system can start either from external 24 VDC or mains power.ACOPOSmulti power supply module, passive, 11 A, AS, wall mounting, 24 V In 1x, integrated line filter

ACOPOSmulti power supply module passive, 22 A, AS, wall mounting

A motor with a hanging load is connected to an ACOPOSmulti drive system with passive power supply module 8B0P with passive motor short circuit brake. If the power supply to the drive system is disconnected and the hanging load begins sinking (due to failure of the motor holding brake, for example), then the motor axis rotates and the DC bus voltage increases. If the DC bus voltage overshoots a value of 15 VDC, then the DC bus is shorted via a thyristor. This limits the speed at which the hanging load sinks.The passive motor short circuit brake is designed for up to 25 kW of power. One fault event is permitted to occur maximum once every 15 minutes for this amount of power.The passive motor short circuit brake is always active and cannot be influenced by the user!The passive motor short circuit brake works without current limiting. As a result, irreparable damage to drive system components (passive power supply module 8B0P, motor, etc.) is possible at excessively high power values.The passive motor short circuit brake is not monitored. It therefore has no effect in the event of component failure!ACOPOSmulti power supply module passive, 22 A, AS, wall mounting, passive motor short circuit brake

ACOPOSmulti power supply module passive, 44 A, AS, wall mounting

ACPMULTI BR 450W 50R IP65

8B0W external braking resistors can be used to dissipate braking energy with B&R drive systems.Braking resistor, 790 W, 33 R, IP20, terminals

ACPMULTI RESOLVER INTERFACE 10KHZ

ACPMULTI INCREMENTAL/SSI ENCODER INTERF.

ACPMULTI DIO INTERFACE

ACPMULTI DO INTERFACE

SERVO_ MOTOR CABLE, 1M, 4X0.75MM²+2X2X0.35MM²

SERVO_ MOTOR CABLE, 3M, 4X0.75MM²+2X2X0.35MM²

SERVO_ MOTOR CABLE, 5M, 4X0.75MM²+2X2X0.35MM²
